CFB-3S Series Three Color Jelly Cup Filling Sealing Machine
CFB-3SSeries Automatic Three-Color Jelly Cup Filling Sealing Machine, which is suitable for 1-3 colors jelly filling and sealing. The finished cup jelly has clear layers, no water droplets, smooth trimming and tight sealing.
online service
Tel:+86-577-65012596
Email: info@shunlongpack.com
Skype: +8615325077939
Whatsapp/Wechat/Viber: +8615325077939
 |
 |
 |
Product features:
CFB-3SSeries Automatic Three-Color Jelly Cup Filling Sealing Machine, which is suitable for 1-3 colors jelly filling and sealing. The finished cup jelly has clear layers, no water droplets, smooth trimming and tight sealing.
Working Process:
Cup Auto feeding→Dust Clean→Filling 1→Cooling→Filling 2→Cooling→Filling 3→Cooling→Liquid Level Control→Sealing film unwinding→Date Printing→Flat Sealing→Photoelectric correction→line sealing→trimming→products push out and conveying。
Optional Device: fruit grain feeding, machine anti-dust cover, Filling system with CIP、Date Printer etc.
This machine adopts latest technologies, such as no drop, no splash, no bubble filling, PID intelligent temperature controller, floating seal, PLC+touch panel control, inverter speed control etc. All the pneumatic parts and electrical parts adopt domestic famous brands and international brands.
Main Technical Parameter:
|
Model |
Speed Cycles/min |
Filling Capacity |
Power |
Cooling Power |
Air Consumption(m3/min) |
Power Supply |
Dimension(m) |
Weight (Ton) |
|
CFB-3S-5 (Φ62) |
13-20 |
30g/20g/30g |
12KW |
10HP |
0.6 |
380V/50Hz |
10.5×0.8×1.7 |
3.5 |
|
CFB-3S-16(Φ48) |
13-20 |
25g/10g/25g |
15KW |
10HP |
1.0 |
380V/50Hz |
10.5×0.8×1.7 |
4.5 |
|
CFB-3S-20(Φ38) |
13-20 |
20g/10g/20g |
15KW |
10HP |
1.0 |
380V/50Hz |
10.5×0.8×1.7 |
4.5 |
|
CFB-3S-24(Φ29) |
13-20 |
20g/5g/20g |
15KW |
10HP |
1.0 |
380V/50Hz |
10.5×0.8×1.7 |
4.5 |
